Clear countdown display
Dual seven-segment LED digits with a wide viewing angle and automatic day/night dimming support clear indication within the pedestrian signal head.
Enlarge imageTraffic electronics
Pedestrian countdown timer
Our countdown timer module provides a visible countdown during the pedestrian blackout period. Its compact panel is designed for integration into pedestrian signal equipment.
A standard version supports established traffic signal installations, while a separate low-voltage version provides a 10–14 V DC supply option for portable and battery-powered equipment. We can help identify the configuration for your controller and power supply.
Key features
Automatic operation
Blackout period detection provides countdown operation without manual programming.
Compact installation
A 270 mm panel is designed for installation in standard 300 mm signal aspects.
Monitoring interfaces
Fault monitoring, visual indicators and monitoring outputs support integration with the signal controller.
Technical specifications
Product specifications and configuration options for your equipment.
Request technical information| Standard version supply | 24–48 V AC/DC |
|---|---|
| Standard version signal inputs | 28–230 V; interface configuration matched to the application |
| Portable version supply | 10–14 V DC |
| Display | Dual seven-segment LED digits |
| Panel size | 270 mm, for a standard 300 mm signal aspect |
| Brightness control | Automatic day/night dimming |
| Timing | Automatic blackout period detection |
| Diagnostics | Fault monitoring, visual indicators and controller monitoring outputs |
Suggested traffic applications
Pedestrian signal equipment
Countdown indication integrated into a suitable signal head.
Portable and battery-powered systems
A dedicated low-voltage version for equipment designed around a 10–14 V DC supply.
Integration and available options
We offer a standard 24–48 V AC/DC version and a separate 10–14 V DC version for portable and battery-powered equipment. Red and green signal interfaces, fault monitoring and controller monitoring outputs support integration with the wider traffic control system.
The compact 270 mm panel fits within a standard 300 mm signal aspect. We can provide mounting, clearly identified connection details and environmental information to support integration into your signal head and roadside enclosure.
Our technical support covers the relevant TOPAS 2581 pedestrian countdown requirements and the applicable UKCA and CE documentation for the selected version and market. We can also help review controller compatibility and the requirements of the completed installation.
Options and customisation
We can review supply, controller interfaces, monitoring connections and enclosure requirements, with product adaptations available to suit your equipment.
Discuss your equipment with us
Tell us about the supply, interfaces and enclosure your project needs.
Enquire about the countdown timer
